H/E Series Fuel Pump 47403

5.00 LBS
Calculated at Checkout
Current stock: 0


H/E Series Fuel Pump 47403

FUELAB continues to lead the way in fuel pump innovation. FUELAB H/E Series fuel pumps are brushless, twin-screw pumps that represent a giant leap in efficiency and reliability. These pumps use a lightweight, DC brushless motor to reduce current draw. Combined with a twin-screw rotor pumping mechanism, they offer superior priming capabilities and improved resistance to cavitation. Available with flow ratings of 250 to 500 lph (@ 13.5 V), they are simply the best pumps on the market today. They feature billet aluminum construction with an integrated controller.

Free Flow Rate:160 gph
Maximum Pressure (psi):125 psi
Inlet Size:-8 AN
Inlet Quantity:One
Inlet Attachment:Female threads
Outlet Size:-8 AN
Outlet Quantity:One
Outlet Attachment:Female threads
Notes:For use with EFI fuel systems.

Features Include:

3-phase DC brushless motor with neodymium magnets
Integrated electronics with no speed control
Billet aluminum, stainless steel construction with flourosilicone seals
Screw-style pumping mechanism
Wet motor design, without dynamic shaft seals
Port O-rings, mating electrical connector, instructions, and performance certification included
8 to16 V operating range
Use only 12 V (6-cell lead acid battery) vehicle systems with or without charging system
All models require bypass regulator or relief valve to avoid over-pressure operating condition
Integrated 2-pin Delphi Weatherpack connector
Integrated cushioned billet bracket system (1/4 in. hardware not supplied)

Fuel Compatibility Includes:

Gasoline (pump and race)
Ethanol (including E85)
